USB2/DATA1 Func
64.
Select the function of the [DATA1] jack.
• -----
: The [DATA1] jack is not used.
• RTTY : Used to send RTTY decoded signals.
• DVdat : Used for low-speed data input and output.
• GPS : Used for the GPS receiver connection for
position data input.
65. GPS Out
When a GPS receiver is connected to the [DATA1]
jack, the GPS position data is input through the jack.
You can select whether or not to send the data from
the COM port ("USB2").
NOTE: You can use this function only when "-----"
or "DVdat" is selected as the "USB2/DATA1 Func"
(63) option, and "GPS" is selected as the "USB2/
DATA1 Func" (64) option.
• OFF : Turns the function OFF.
• DATA1 ➔ USB2 : Sends the GPS position data from
the COM port ("USB2").
DVdat/GPS Out Baud
66.
Set the DV or GPS data transfer speed to 4800 or
9600 bps.
RTTY Decode Baud
67.
Set the RTTY decode monitor speed to 300, 1200,
4800, 9600 or 19200 bps.
Calibration Marker
68.
Use as a simple frequency check of the transceiver.
See page 179 for calibration procedure.
NOTE: Turn OFF the calibration marker after check-
ing the frequency of the transceiver.
• OFF : Calibration marker OFF
• ON : Calibration marker ON
69. REF Adjust
During frequency calibration, set the internal refer-
ence frequency to between 0% and 100% range in 1%
steps.
NOTE: The default setting is different for each
transceiver.
(Default: -----/[GPS ])
(Default: OFF)
(Default: 4800)
(Default: 9600)
(Default: OFF)
