Icom i9100 Instruction Manual page 194

18
CONTROL COMMAND
D Command table (continued)
Cmd. Sub cmd.
15 01
02 0000 to
11 0000 to
12 0000 to
13 0000 to
14 0000 to
16 02
12
22
40
41
42
43
44
45
46
47
48
4A
4B
4C
4F
50
55
56
57
58
185
Data Description
00 Read squelch status (squelch close)
01 Read squelch status (squelch open)
Read S-meter level
(0000=S0, 0120=S9, 0240=S9+60 dB)
0255
Read RF power meter
(0000=0%, 0141=50%, 0215=100%)
0255
Read SWR meter
(0000=SWR1.0, 0041=SWR1.5,
0255
0081=SWR2.0, 0120=SWR3.0)
Read ALC meter
(0000=Min. to 0120=Max.)
0255
Read COMP meter
(0000=0 dB, 0120=15 dB, 0240=30 dB)
0255
00 Send/read Preamp OFF
01 Send/read Preamp ON (144/430/1200 MHz)
Send/read Preamp 1 ON (HF/50 MHz)
02 Send/read Preamp 2 ON (HF/50 MHz)
01 Send/read AGC FAST
02 Send/read AGC MID
03 Send/read AGC SLOW
00 Send/read Noise Blanker OFF
01 Send/read Noise Blanker ON
00 Send/read Noise Reduction OFF
01 Send/read Noise Reduction ON
00 Send/read Auto Notch function OFF
01 Send/read Auto Notch function ON
00 Send/read Repeater tone OFF
01 Send/read Repeater tone ON
00 Send/read Tone squelch OFF
01 Send/read Tone squelch ON
00 Send/read Speech compressor OFF
01 Send/read Speech compressor ON
00 Send/read Monitor function OFF
01 Send/read Monitor function ON
00 Send/read VOX function OFF
01 Send/read VOX function ON
00 Send/read BK-IN function OFF
01 Send/read Semi BK-IN function ON
02 Send/read Full BK-IN function ON
00 Send/read Manual notch function OFF
01 Send/read Manual notch function ON
00 Send/read AFC function OFF
01 Send/read AFC function ON
00 Send/read DTCS OFF
01 Send/read DTCS ON
00 Send/read VSC function OFF
01 Send/read VSC function ON
00 Send/read Twin Peak Filter OFF
01 Send/read Twin Peak Filter ON
00 Send/read Dial lock function OFF
01 Send/read Dial lock function ON
00 Send/read 1st IF filter 3 kHz
01 Send/read 1st IF filter 6 kHz
02 Send/read 1st IF filter 15 kHz
00 Send/read DSP filter type SHARP
01 Send/read DSP filter type SOFT
00 Send/read manual notch width WIDE
01 Send/read manual notch width MID
02 Send/read manual notch width NAR
00 Send/read SSB transmit bandwidth WIDE
01 Send/read SSB transmit bandwidth MID
02 Send/read SSB transmit bandwidth NAR
Data
Cmd. Sub cmd.
16 59 00 Send/read Sub band OFF
01 Send/read Sub band ON
5A 00 Send/read Satellite mode OFF
01 Send/read Satellite mode ON
5B 00 Send/read DSQL/CSQL OFF (DV mode
only)
01 Send/read DSQL ON (DV mode only)
02 Send/read CSQL ON (DV mode only)
17 see p. 191 Send CW messages
19 00 Read the transceiver ID
1A 00 see p. 195 Send/read memory contents
01 see p. 191 Send/read band stacking register con-
tents
02 see p. 191 Send/read memory keyer contents*
03 00 to 49 Send/read the selected filter width
(AM: 00=200 Hz to 49=10 kHz;
other than AM modes: 00=50 Hz to
40/31=3600 Hz/2700 Hz)
04 00 to 13 Send/read the selected AGC time constant
(00=OFF, AM: 01=0.3 sec. to 13=8.0 sec.
SSB/CW/RTTY: 01=0.1 sec. to 13=6.0 sec.)
05 0001 0000 to Send/read LCD contrast level
(0000=0% (low) to 0255=100% (high))
0255
0002 0000 to Send/read LCD backlight brightness level
(0000=0% (dark) to 0255=100% (bright))
0255
0003 0000 to Send/read beep level
(0000=0% to 0255=100%)
0255
0004 00 Send/read beep level limit OFF
01 Send/read beep level limit ON
0005 00 Send/read confirmation beep OFF
01 Send/read confirmation beep ON
0006 00 Send/read band edge beep OFF
01 Send/read band edge beep ON
(Beep sounds with a default band)
02 Send/read band edge beep with user set-
ting ON
03 Send/read band edge beep with user set-
ting/TX limit ON
0007 0050 to Send/read beep audio frequency for MAIN
0200 Band
(0050=500 Hz to 0200=2000 Hz)
0008 0050 to Send/read beep audio frequency for SUB
0200 Band
(0050=500 Hz to 0200=2000 Hz)
0009 00 Send/read Auto selection for [RF/SQL]
01 Send/read SQL selection for [RF/SQL]
02 Send/read RF+SQL selection for [RF/SQL]
0010 00 Send/read Meter Peak Hold function OFF
01 Send/read Meter Peak Hold function ON
0011 00 Send/read FM/DV Center Error function
OFF
01 Send/read FM/DV Center Error function
ON
0012 00 Send/read Time-Out Timer OFF
01 Send/read 3 min. Time-Out Timer
02 Send/read 5 min. Time-Out Timer
03 Send/read 10 min. Time-Out Timer
04 Send/read 20 min. Time-Out Timer
05 Send/read 30 min. Time-Out Timer
0013 00 Send/read PTT Lock function OFF
01 Send/read PTT Lock function ON
0014 00 Send/read Quick Split function OFF
01 Send/read Quick Split function ON
0015 see p. 192 Send/read Split offset frequency
Description
