D Command table

Data
Cmd. Sub cmd.
00 see p. 190 Send operating frequency for transceive
01 see p. 190 Send operating mode for transceive
02 see p. 191 Read band edge frequencies
03 see p. 190 Read operating frequency
04 see p. 190 Read operating mode
05 see p. 190 Send operating frequency
06 see p. 190 Send operating mode
07 Select VFO mode
00 Select VFO A
01 Select VFO B
A0 Equalize VFO A and VFO B
B0 Exchange MAIN and SUB Bands
D0 Select MAIN Band
D1 Select SUB Band
08 Select Memory mode
0001 to Select Memory channel
(0001=M-CH01 to 0099=M-CH99,
0105
0100=1A, 0101=1b, 0102=2A, 0103=2b,
0104=3A, 0105=3b)
0106 Select Call channel
00 to 19 Select Satellite Memory channel
(00=Satellite M-CH00 to 19=Satellite
M-CH19)
09 Memory write
0A Memory copy to VFO
0B Memory clear
0C Read offset frequency
0D Send offset frequency
0E 00 Scan stop
01 Programmed/memory scan start
02 Programmed scan start
∂F scan start
03
12 Fine programmed scan start
Fine ∂F scan start
13
22 Memory scan start
23 Select memory scan start
24 Mode select scan start
Set ∂F scan span ±5 kHz
A1
Set ∂F scan span ±10 kHz
A2
Set ∂F scan span ±20 kHz
A3
Set ∂F scan span ±50 kHz
A4
Set ∂F scan span ±100 kHz
A5
Set ∂F scan span ±500 kHz
A6
Set ∂F scan span ±1 MHz
A7
B0 Set as non-select channel
B1 Set as select channel
( The previously set number by CI-V is set
after turning power ON, or "1" is selected
if no selection is performed.)
D0 Set scan resume OFF
D3 Set scan resume ON
0F Read Split function or duplex setting
(00=OFF, 01=ON, 11=DUP–, 12=DUP+)
00 Set the Split function OFF
01 Set the Split function ON
10 Set simplex operation
11 Set DUP– operation
12 Set DUP+ operation
Description
Cmd.
CONTROL COMMAND
Data
Sub cmd.
10 00 Send/read the tuning step 10 Hz (1 Hz)
01 Send/read the tuning step 100 Hz
02 Send/read the tuning step 1 kHz
03 Send/read the tuning step 5 kHz
04 Send/read the tuning step 6.25 kHz
05 Send/read the tuning step 9 kHz
06 Send/read the tuning step 10 kHz
07 Send/read the tuning step 12.5 kHz
08 Send/read the tuning step 20 kHz
09 Send/read the tuning step 25 kHz
10 Send/read the tuning step 50 kHz
11 Send/read the tuning step 100 kHz
12 Send/read the tuning step 1 MHz (except
for HF/50 MHz band)
11 00 Send/read attenuator OFF
20 Send/read 20 dB attenuator
12 00 Send/read ANT1 selection
01 Send/read ANT2 selection
13 00 Announce operating frequency, operating
mode and S-meter level with voice syn-
thesizer
01 Announce operating frequency and S-
meter level with voice synthesizer
02 Announce operating mode with voice syn-
thesizer
14 01 0000 to Send/read [AF] position
(0000=max. CCW, 0255=max. CW)
0255
02 0000 to Send/read [RF/SQL] position (RF gain
0255 level)
(0000=max. CCW, 0255=11 o'clock)
03 0000 to Send/read [RF/SQL] position (squelch
0255 level)
(0000=11 o'clock, 0255=max. CW)
06 0000 to Send/read [NR] position
(0000=max. CCW, 0255=max. CW)
0255
07 0000 to Send/read inner [TWIN PBT] position
(0000=max. CCW, 0128=center,
0255
0255=max. CW)
08 0000 to Send/read outer [TWIN PBT] position
(0000=max. CCW, 0128=center,
0255
0255=max. CW)
09 0000 to Send/read [CW PITCH] position
(0000=max. CCW, 0128=center,
0255
0255=max. CW)
0A 0000 to Send/read [RF POWER] position
(0000=max. CCW to 0255=max. CW)
0255
0B 0000 to Send/read [MIC GAIN] position
(0000=max. CCW to 0255=max. CW)
0255
Send/read [KEY SPEED] position
0C 0000 to
(0000=max. CCW to 0255=max. CW)
0255
0D 0000 to Send/read [NOTCH] position
(0000=max. CCW, 0128=center,
0255
0255=max. CW)
0E 0000 to Send/read COMP level
(0000=0 to 0255=10)
0255
0F 0000 to Send/read Break-IN Delay setting
(0000=2.0d to 0255=13.0d)
0255
12 0000 to Send/read NB level
(0000=0% to 0255=100%)
0255
15 0000 to Send/read Monitor gain
(0000=0% to 0255=100%)
0255
16 0000 to Send/read VOX gain
(0000=0% to 0255=100%)
0255
17 0000 to Send/read Anti VOX gain
(0000=0% to 0255=100%)
0255
18 0000 to Send/read CONTRAST level
(0000=0% to 0255=100%)
0255
19 0000 to Send/read BRIGHT level
(0000=0% to 0255=100%)
0255
18
