SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
Icon The icon(s) shown in bold turns off when:
1234 Note: Used for SVP QoS only and not present when using Wi-Fi Standard QoS or
CCXv4.
The SRP link is established; all network stack initialization is complete, proceeding with
application-specific initialization.
123 SIP application startup. Icon 3 is extinguished if a generic SIP config file is found.
12 Icon 2 is extinguished if a handset specific SIP config file is found.
(no icons) Handset is attempting to register each of the specified line contacts.
Registering
(no icons)
Handset has registered with at least one contact on one proxy server. Initialization is
EXT.
complete. The handset is in standby mode ready to receive and place calls. The line one
XXXXX
contact is displayed.

Handset Modes

80
During the last three steps of this process, the handset contacts the SIP
TFTP server and downloads general information about the proxy
server(s), downloads specific information pertaining to the handset,
registers with the proxy server(s), and verifies handset credentials.
Once this process is complete, the handset is ready to use.
If the username and password have not been defined in the Admin
menu, you will be prompted to enter both of these items before the
extension number can display. The user name must correspond to the
configuration file that contains user-specific information. If the file is
not found, an error message will appear and the handset will restart.
See Chapter 5 Programming the SIP Handset Features, section SIP TFTP
Server Configuration Files.
Standby mode (on-hook)
In standby mode, the handset is waiting for an incoming call or for
the user to place an outgoing call. The extension number is shown on
the display and there is no dial tone. In this mode, the handset is
conserving battery power and wireless LAN bandwidth.
When an incoming call arrives, the handset rings; the handset enters
the active mode and remains so until the call is ended. The call is
PN: 1725-36038-001-L.doc
