Polycom SpectraLink 8020 Administration Manual page 105

Radio stats
Radio error threshold exceeded
(Sent if TX drop rate exceeds 2%
or TX or RX retry rate exceeds
5%)
Probe Recovery
LockUpRecovery
DCA initiated radio reset
SW ERROR
Checked in to server [IP
addresses]
DCA unknown MgmtAction
category code=###
CHARGER-Vbat: ##Mv
PN: 1725-36038-001-L.doc
‡ Present only when the specific fast handoff method (CCKM, OKC)
has been enabled.
Messages are formatted like the following example:
Jan 1 00:01:26.72 0090.7a02.2a1b (172.16.0.46) [001a]
RStat: AP 00:40:96:48:1D:0C (-56 dBm), Sent 783523,
Recvd 791342, MSnt 245, MRcd 5674, BSnt 43, BRcd 10783,
TX drop 43 (0.0%), TX retry 578 (1.2%), RX retry 1217
(1.6%)
AP MAC
AP signal strength
Directed packets sent
Directed packets received
Multicast packets sent
Multicast packets received
Broadcast packets sent
Broadcast packets received
TX dropped count
TX drop rate (over last 5 seconds)
TX retry count
TX retry rate (over last 5 seconds)
RX retry count
RX retry rate (over last 5 seconds)
Same as radio stats
Probe Recovery Count
Lockup Recovery Count
Reset count when Reset occurred
Reset count at the time when the syslog was sent
Parameters are "file name", "line number",
"proprietary parameter 1", "proprietary parameter
2", OTADL firmware version, Functional Firmware
version, Phintl version, and phone license type.
Handset checked into AVPP. Parameters are
AVPP IP address, OTADL firmware version,
Functional Firmware version, and Phintl version.
Unexpected management action from access
point.
Current battery voltage.
Diagnostic Tools
105
