Polycom SpectraLink 8020 Administration Manual page 112

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
Message Description
Auth Timeout x...x = AP MAC address.
xxxxxxxxxxxx Handset did not receive authentication
response from AP; displays MAC of
failing AP.
Bad Code Type xx xx, yy = software license types.
Expected Code Handset software does not match
Type yy current handset license selection.
Bad Config Some needed configuration parameter
has not been set.
The handset has not had an SSID
Bad SSID
entered.
Bad Phintl File Handset software download files are
incorrect or corrupted.
Handset software download files are
Bad Program File
incorrect or corrupted.
Bad SIP TFTP IP A bad unicast address has been
entered for the SIP TFTP server in
static entry mode.
(battery icon), Low battery.
Battery Low,
beep (audio)
Battery Failure The Battery Pack is not functioning.
Battery Failed Battery Pack is damaged or
incompatible with handset.
Can't Renew y...y = DHCP server IP address.
DHCP DHCP server is not responding to
yyy.yyy.yyy.yyy
initial renewal attempt.
112
Action
Check handset and AP security
settings.
Ensure AP is configured per VIEW
Configuration Guide.
Try another AP.
Download new software from the
Polycom website per Software
Maintenance.
Check all required handset
configuration parameters for valid
settings.
Statically configure an SSID in the
Admin menu.
Download new software from the
Polycom website per Software
Maintenance.
Download new software from the
Polycom website per Software
Maintenance.
Re-enter the correct IP address in the
administrative menus for static IP
addresses.
In call: the battery icon displays and a
soft beep will be heard when the user is
on the handset and the battery charge
is low. User has 15–30 minutes of
battery life left.
Not in call: The battery icon displays
whenever the battery charge is low The
message Battery Low and a beep
indicate a critically low battery charge
when user is not on the handset. The
handset will not work until the Battery
Pack is charged.
Replace the Battery Pack with a new or
confirmed SpectraLink Battery Pack.
Only SpectraLink Battery Packs will
work.
Replace the Battery Pack with a new or
confirmed SpectraLink Battery Pack.
Only SpectraLink Battery Packs will
work.
Configuration problem. Check the IP
address configuration in the DHCP
server.
PN: 1725-36038-001-L.doc
