Appendix B: Proxy Server Command Table - Polycom SpectraLink 8020 Administration Manual

Appendix B: Proxy Server
Command Table
Parameter
PROXYn_ADDR
PROXYn _DOMAIN
PN: 1725-36038-001-L.doc
Use the following parameters when programming the configuration
files. See the sample configuration files following this table for more
detailed information.
Value
xxx.xxx.xxx.xxx:pppp
or
proxyname:pppp
Domain name
Description
Proxy address. One proxy
address is required but
additional proxy
addresses may be used to
register secondary line
appearances.
Domain served by this
proxy server.
13
Notes
n = 1, 2, 3
xxx.xxx.xxx.xxx = IP4
address
pppp = port (optional, 5060
is the default)
proxyname = computer
name (DHCP only)
n = 1, 2, 3
DOMAIN = [example:
spectralink.com]
Can be omitted if a specific
proxy domain name is not
defined at the proxy server.
If omitted, defaults to the IP
address of the proxy server
(see above).
123
