Polycom SpectraLink 8020 Administration Manual page 58

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
58
SIP TFTP Server IP The IP address of a TFTP server on your
network, which holds SIP configuration files. In static mode, this
parameter must be configured with an IP address. In DHCP
mode, the SIP TFTP server may be specified by defining the
address on the DNS server for the name "siptftp" If this is not
defined, the address specified in option 66 or the boot server/next
server (siaddr) field will be used. See Chapter 4, SIP Integration
Factors.
OAI Server IP The IP address of the SpectraLink 8000 OAI
Gateway. If using Static IP configuration, this is simply the IP
address of the SpectraLink 8000 OAI Gateway. If DHCP is being
used, the handset will try the DHCP option 152.
SSID
Enter the SSID.
WLAN Settings
Select between Custom and CCX modes. The Custom mode allows
explicit control of all of the security and QoS settings. Using CCX
mode automatically enables the CCXv4 features and functions, with
only the 802.1X mechanism needing to be selected.
Custom – Security
Handset security setting should match exactly the settings in your
APs. Consult the VIEW Configuration Guide for the APs installed in
your facility for information on which of the security methods are
certified.
Encryption keys, Username and Password display as they are
entered. For security reasons, these items will not display when a
user returns to the Administration menu.
*NONE disables any 802.11 encryption or security authentication
mechanisms.
WEP (Wired Equivalent Privacy) is a wireless encryption protocol that
encrypts data frames on the wireless medium allowing for greater
security in the wireless network. If WEP is required at this site, you
must configure each handset to correspond with the encryption
protocol set up in the APs. Select the entries from the options below to
enable the handset to acquire the system.
PN: 1725-36038-001-L.doc
