Polycom SpectraLink 8020 Administration Manual page 142

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
# 0 which means the phone will not send keep_alives to PROXYn.
#
# If the phone failes to get a keepalive response within the SIP 32 second
# timeout, the keepalives are terminated for that PROXY until the next successful
# registration to the PROXY.
#
# This parameter is REQUIRED on Asterisk Business Edition with the Polycom 8002
# phone. For Polycom 8020/8030 phones, this parameter is required when they are
# operating in WI-FI standard QoS mode.This is because Linux, the OS running Asterisk,
# has a ARP Cache flushing mechanism. This feature serves to refresh the ARP Cache for the 8002
phones.
# For 8020 and 8030 phones, operating in SVP mode ARP Cache is refreshed by the SVP server.
# If the phones are operating in standard based QoS method ARP cache refresh has to be done by
phone.
#
# The value of this parameter for phones should be just less than the
# minimum ARP Cache flushing time on the Linux box running Asterisk.
# this minimum flushing time is 15 seconds, so the parameter needs to be set for
# 14 seconds or less.
# what this minimum value is, however 14 seconds should work fine.
#
# The lower this setting, the more the impact on the phone's standby battery life.
# (8002 phones running version 130.003 and earlier code ignore this parameter if
# present)
# 8020/8030 phones running version 131.017 and earlier code ignore this parameter if
# present)
#PROXY1_KEEPALIVE_SECS=14
#-----------------------------------------------------------------------------------------------#
# PROXYn_REREG_SECS specifies the the re-registration interval for a PROXY.
# is the requested expiration interval sent in the REGISTER request message.
# be set to anything between 35 and 3600 seconds.
# The default value (which is applied if no parameter is supplied in this file) is
# 3600 which means the phone will attempt to register every 3580 seconds, if the
# server's response interval doesn't take precedence (see below).
#
# If the server has a lower maximum setting or a higher minimum setting that
# this value then the server's response will take precedence and this parameter
# will be ignored.
#
# The phone will always attempt to re-register with the PROXY 20 seconds prior to
# the expiration interval.
# server's response interval doesn't take precedence, then the phone will attempt
# to re-register every 15 seconds.
#
# The lower this setting, the more the impact on the 8002's standby battery life.
#(8002 phones running version 130.003 and earlier code ignore this parameter if
# present)
#PROXY1_REREG_SECS=3600
#-----------------------------------------------------------------------------------------------#
# PROXYn_CALLID_PER_LINE controls sending of same Call-ID header
# field for registrations sent to a particular registrar."
# If this is enable we will send
# This may be needed for Mitel 3300 Controller software prior to Release 9
#PROXYn_CALLID_PER_LINE = enable
#-----------------------------------------------------------------------------------------------#
# PROXY1_MAIL_SUBSCR is who we should subscribe to for mail center notifications
# This is needed only if the user is not subscribed automatically at registration.
# It is almost never required in current versions of Asterisk to specify this.
# Mitel, Cisco, Interactive Intelligence, and Pingtel also accept this parameter
142
For other Linux Distributions, you may have to determine
Thus, if this parameter is set to 35 seconds, and the
Call-ID headers differently.
For Redhat
This
It can
PN: 1725-36038-001-L.doc
