Polycom SpectraLink 8020 Administration Manual page 38

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
38
Favorites required for each handset/user, if any.
—
2. Retrieve the SIP_xxxxxx.cfg file from the .zip.
3. PROXYn settings: These should match the allusers settings
except if a specific handset needs an override.
4. Enter the username and password at # AUTH =.
Authentication credentials are normally not stored in the file for
security reasons, but the option is available if desired.
For lines on proxies of type NECSIP and SHORETEL the LINEn
AUTH setting should be used instead as each NEC line must
respond to any authentication challenge using a single UN/PW pair.
Enter specific line definitions
Each handset may have several lines. These would be labeled as
LINE1, LINE2, LINE3 and so forth as shown in the sample .cfg file in
Appendix C.
5. LINEn: Enter the dial number of the handset You can enter up
to four additional lines (e.g. LINE2 etc.). E.g.
LINE1 = 3001
6. LINEn_PROXY is the number of the proxy server this line
should register with, as defined in the sip_allusers.cfg file. E. g.
LINE1_PROXY = 1
7. LINEn_SECONDARY_PROXY is the proxy server to be used in
case the primary proxy server fails. This command will only be
implemented when the line has a proxy type of MITEL. E.g.
LINE1_SECONDARY_PROXY = 2
A line can only use a secondary proxy if it and the primary proxy
(defined with LINEn_PROXY) are both of PROXYn_TYPE = MITEL.
If both the primary and secondary proxies are not type MITEL, the
secondary definition will be ignored.
The Mitel Communications Director (MCD) 4.0 or greater is the only
server that supports this redundancy feature.
8. LINEn_CALLID is the data you wish to appear on the caller ID
of the far end of a call. E.g.
LINE1_CALLID = John Doe
PN: 1725-36038-001-L.doc
