Polycom SpectraLink 8020 Administration Manual page 140

SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
#PROXY1_PRACK = enable
#PROXY1_REREG_SECS=3600
#PROXY1_KEEPALIVE_SECS=14
#PROXY1_DOMAIN =
#PROXY1_CALLID_PER_LINE = disable
#PROXY1_MAIL_ACCESS = 5000
#-----------------------------------------------------------------------------------------#
## FOR PROXY1_TYPE = DELTAPATH
#PROXY1_ADDR = 10.240.240.226:5060
Address
#PROXY1_KEYPRESS_2833 = enable
#PROXY1_KEYPRESS_INFO = disable
#PROXY1_HOLD_IP0 = disable
#PROXY1_PRACK = enable
#PROXY1_REREG_SECS=3600
#PROXY1_KEEPALIVE_SECS=14
#PROXY1_DOMAIN = axlx.engr.local
#PROXY1_CALLID_PER_LINE = disable
#PROXY1_MAIL_ACCESS = 7999
#-----------------------------------------------------------------------------------------#
## FOR PROXY1_TYPE = SHORETEL
#PROXY1_ADDR = 172.29.102.212:5060
#PROXY1_KEYPRESS_2833 = enable
#PROXY1_KEYPRESS_INFO = disable
#PROXY1_HOLD_IP0 = disable
#PROXY1_PRACK = enable
#PROXY1_REREG_SECS=3600
#PROXY1_KEEPALIVE_SECS=14
#PROXY1_DOMAIN = asia.polycom.com
#PROXY1_CALLID_PER_LINE = disable
#PROXY1_MAIL_ACCESS = 102
###############################################################################################
##### THIS SECTION EXPLAINS THE PROXY_N PARAMETERS IN MORE DETAIL AND GIVES FORMAT EXAMPLES ####
# One PROXYn_ADDR (PBX/Call Server) entry is required, additional ones are optional as you
# can register secondary line appearances with other PROXY servers
#
#PROXY1_ADDR = 172.29.102.131:5060
#PROXY2_ADDR = 172.29.0.140:5060
#-----------------------------------------------------------------------------------------------#
# For each proxy of type NECSIP, one PROXYn_CONF_IP_ADDRESS is required. This value is
# the address of NEC PBX's IP PAD card.
#
#PROXY1_CONF_IP_ADDRESS
#-----------------------------------------------------------------------------------------------#
# To test ININ Redundancy PROXY1_FAILOVERIP is required. This value is the secondary IP address
# of the ININ server. If the primary server fails we need to use this address to make the calls.
#
#PROXY1_FAILOVERIP = 172.24.144.136
#-----------------------------------------------------------------------------------------------#
#ProxyDomain can be omitted if a specific proxy domain name is not defined at the
140
# Put Your SIP Domain's Name Here
# Put Your Voice Mail Sytem's Pilot Number here
# replace the ip address with the Asterisk Server's
# Replace this with your SIP Domain's name
# Put Your Voice Mail Sytem's Pilot Number here
# replace the ip address with the Shoretel's Address
# Put Your SIP Domain's Name Here
# Put Your Voice Mail Sytem's Pilot Number here
= 172.29.102.131
PN: 1725-36038-001-L.doc
