#PROXY1_REREG_SECS
#PROXY1_KEEPALIVE_SECS
#PROXY1_DOMAIN
# Replace this with your SIP Domain's name
#PROXY1_CALLID_PER_LINE = disable
#PROXY1_MAIL_ACCESS
# Put Your Voice Mail Sytem's Pilot Number here
#-----------------------------------------------------------------------------------------#
## FOR PROXY1_TYPE
#PROXY1_ADDR
# replace the ip address with the Shoretel's Address
#PROXY1_KEYPRESS_2833
#PROXY1_KEYPRESS_INFO
#PROXY1_HOLD_IP0
#PROXY1_PRACK
#PROXY1_REREG_SECS
#PROXY1_KEEPALIVE_SECS
#PROXY1_DOMAIN
# Put Your SIP Domain's Name Here
#PROXY1_CALLID_PER_LINE = disable
#PROXY1_MAIL_ACCESS
# Put Your Voice Mail Sytem's Pilot Number here
#######################################################################################
##### This section describes call logs on phone
# CALL_LOGGING enables to log the Incoming/Answered and Missed calls happened on the phone.
# Disabling call logs will not log any of the calls on the phone.
# CALL_LOGGING = disable
#-----------------------------------------------------------------------------------------#
#######################################################################################
##### This section describes how to add Favorites #####################################
#The Favorite parameter expects a number and a name separated by the colon" ; ".
#The Number field can be placed without quotes but the name field should be placed in double
quotes.
#And also the number field can take special characters like *,#..
# Favorites in the allusers file will be present in the favorites on all phones
# The username can be blank and can include escaped chars
# Useful features can be included such as call forwarding or dialing voicemail
#FAVORITE = "1234"; "Site Security"
#FAVORITE = "*98"; "Call Forwarding"
#
# Favorites can also be configured to prompt users to enter more digits. Users will
# be prompted with characters inside the <>'s.
# In the below example if the Feature Access Code for call forwarding is #21
# When the user selects the Favorites option and then Call Forward they would
# see "Call Forward Enter Destination:"
# They would then have a chance to enter the fwd destination before pressing the send key
#FAVORITE = #21<Enter Destination:>; "Call Forward"
# In the example below the user would be prompted "Call Pickup Pickup Number:
# to enter a call pickup number # for a call pickup Feature Access Code starting with *5
#FAVORITE = *5<Pickup Number:>; "Call Pickup"
# If user wants to add a comment for a FAVORITE, it should be added on the next line (not on the
same line where a FAVORITE is defined).
###############################################################################################
##### THIS SECTION EXPLAINS THE PROXY_N PARAMETERS IN MORE DETAIL AND GIVES FORMAT EXAMPLES ####
# One PROXYn_ADDR (PBX/Call Server) entry is required, additional ones are optional as you
# can register secondary line appearances with other PROXY servers
PN: 1725-36038-001-L.doc
= 3600
= 14
= axlx.engr.local
= 7999
= SHORETEL
= 172.29.102.212:5060
= enable
= disable
= disable
= enable
= 3600
= 14
= asia.polycom.com
= 102
