SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP

Network Config

56
Ekahau clients are not expected to find the EPE automatically.
Regardless of the handset's selection of DHCP or static IP, the EPE
IP address must be statically entered in the Ekahau admin menus or
HAT.
ELP Port Allows the user to select the port number which ELP updates
get sent to at the Location Server IP address. It must match the value
configured in the Ekahau Positioning Engine for proper functionality.
The ELP port number must be greater than zero and less than 65536.
Default is 8552. Enter the port number and press
IP Addresses
There are two modes in which the handset can operate: DHCP-
enabled or Static IP. Select the mode for operation from the IP
Address menu:
* Use DHCP Will use Dynamic Host Configuration Protocol to assign
an IP Address each time the handset is turned on. If DHCP is enabled,
the handset also receives all other IP Address configurations from the
DHCP server.
Static IP Allows you to manually set a fixed IP Address. If selected,
the handset will prompt for the IP addresses for each configurable
network component. When entering addresses, enter the digits only,
including leading zeroes. No periods are required.
Regardless of the mode in which the handset is operating, the
following components are required and must be configured as part of
the SIP system:
Phone IP The IP address of the handset. This is automatically
assigned if DHCP is used. If using Static IP configuration, you
must obtain a unique IP address for each handset from your
network administrator.
Default Gateway and Subnet Mask
when using a complex network, which includes routers. Both of
these must be configured either with an IP address under Static IP
(not set to 000.000.000.000 or 255.255.255.255) or with DHCP for
the handset to contact any network components on a different
subnet. If configured on the DHCP server, use option 3 for the
NavOK to save.
Used to identify subnets,
PN: 1725-36038-001-L.doc
