Polycom SpectraLink 8020 Administration Manual page 143

# If you are using Asterisk (non-business edition) before v1.2, this is necessary.
# This example is specific for a line number:3001
#PROXY1_MAIL_SUBSCR = sip:3001@172.29.102.160
#PROXY1_MAIL_SUBSCR = sip:3001@yourdomain.name.here
# //////////////////////////////////////////////////////////////////////////////////////////////#
# ////// The administrator should enter the extension specific configuration
# ////// parameters for this extension in this section of the file
# /////////////////////////////////////////////////////////////////////////////////////////////#
# Authentication credentials (Normally not stored in this file for security reasons)
# AUTH = username; password
# For lines on proxies of type NECSIP and SHORETEL, the LINEn_AUTH setting should be used instead
# as each NEC line must respond to any authentication challenge using a single UN/PW pair.
#AUTH = 3001; 3001
# ////// For CCME, the value for LINEn_CALLID cannot have commas or special characters.
# ////// If a comma or a special character is in this command, phone will display an
# ////// error message "Bad Request 'Mal".
#-----------------------------------------------------------------------------------------------#
# Line definitions
# Each definition should have LINEn, LINEn_PROXY and LINEn_CALLID
# LINEn is the dial number
# LINEn_PROXY is the PROXYn server this line should register with, typically
# defined in sip_allusers.cfg.
# LINEn_CALLID is shown on the standby display of 8020/8030 phones but not 8002
# or e/h340/i640 phones.
# to alternative forms defined in the Asterisk configuration files for
# display at the far end of a phone call.
# LINEn_AUTH is a means of associating a particular user-name/Password pair with a specific
line.
# Linen_AUTH method of authentication must be used on PROXY types; NEC and SHORETEL
# Like AUTH, there is a security risk associated with storing authentication credentials in
this file.
# alternatively, the LINEn_AUTH setting information can be administered via the SIP Reg menus.
# Up to 5 line definitions can be made for each user
# Line definitions do not necessarily have to have different extensions
# ////// For CCME, the value for LINEn_CALLID shouldn't have commas or special characters.
# ////// If found, the phone will display an error message "Bad Request 'Mal".
# LINEn_SECONDARY_PROXY is only valid if the LINEn_PROXY is type MITEL
# and the secondary proxy specified here is also type MITEL and they do not
# both indicate the same proxy. If any of these things are not true, the
# secondary will be ignored.
LINE1 = 3001
LINE1_PROXY = 1
LINE1_SECONDARY_PROXY = 2
LINE1_CALLID = User Name 1
LINE1_AUTH = 3001; 3001
# Two lines may map to the same extension to allow second incoming calls.
LINE2 = 3002
LINE2_PROXY = 1
LINE2_SECONDARY_PROXY = 2
LINE2_CALLID = User Name 2
LINE2_AUTH = 3002; 3002
LINE3 = 3003
PN: 1725-36038-001-L.doc
The Asterisk Server converts the callID information
# MITEL only
# MITEL only
Sample SIP Configuration Files
143
