aintenance

Users

The printer is designed so that the user can perform the following maintenance tasks without calling a
service technician:
Removing and replacing the Toner Cartridge
Removing and replacing the Waste Toner Container
Replacing the Fuser Felt Wiper
Cleaning the Fuser Heat Roller
Cleaning the Transfer Corona Wire
Cleaning the Charge Corona Wire
Removing and replacing the OPC Drum Unit
Removing and replacing the Developer Unit
Removing and replacing the Ozone Filter
Removing and replacing the Fuser Unit
When you are called to service the printer, check these items to be sure that the owner is replacing them
according to the schedule below. This user maintenance schedule provides the owner with the best
quality printing.

Service Technicians

Service personnel will provide all other maintenance on these printers according to warranty and service
agreements.
WARNING:
Chapter 1 – Introduction
Since this unit uses laser light, even though the power is less than 1
milliwatt at 780 nm, it is wise to protect your eyes whenever the top of
the printer (clamshell) is open and the Laser Scanning Unit (LSU) is
exposed and functioning. We recommend that you wear protective
eyewear capable of attenuating laser light at 780 nm to safe levels or
cover the LSU cover glass to prevent the laser light from escaping
during servicing.
1–3
