Printronix L1024 Maintenance Manual page 30

Continuous form laser printer
Hide thumbs Also See for L1024:
Table of Contents

Advertisement

2–12
Detail 2–1. Removing Top Cover and Hinge Covers
1. Lift Front Cover,
then disengage
rear Locking Tabs.
2. Depress tab to
remove Hinge
Cover.
Chapter 2 – Clamshell
