1. Remove the Safety Lever Spring, being careful not to damage it, then remove 1 E-ring and
remove the Safety Lever. See Figure 12–4 .
NOTE:
2. Remove the Clamshell Latch Spring, then remove 1 E-ring and remove the Clamshell Latch.
See Figure 12–4 .
3. Remove 1 E-ring, then remove the Waste Toner Container Lever.
4. Remove 1 Screw, then remove the Toner Sensor Board.
5. Remove 1 CE-ring, then remove the Developer Clamp.

12.6.2 Reassembly and Replacement

Reverse all of the Steps listed above.

12.6.3 Adjustment

No adjustment of the Left Side Frame is necessary.

12.6.4 Troubleshooting

See Chapter 13 for troubleshooting information.
Chapter 12 – Covers, Frame, and Backplane Board
The curved end of the Safety Spring goes toward the Frame; the straight
end goes toward the Lever.
12–17
