7. Remove the printer from the phone book. Remove the Screw from the left side of the Base
Frame that secures the Engine Controller Board.
8. Unplug the Engine Controller Board from the Backplane Board and remove the Engine
Controller Board from the printer through the opening in the rear of the printer.

9.7.2 Reassembly and Replacement

Reverse Steps 1 through 8 above.

9.7.3 Adjustment

No adjustment of the Engine Controller Board is necessary.

9.7.4 Troubleshooting

See Chapter 13 for troubleshooting information.
9–16
Figure 9–4. Removing Bottom Cover
Bottom
Cover
Locking
Tabs
Chapter 9 – Controllers and Floppy Disk Drives
