2.6 Left and Right Catch Assemblies

2.6.1 Removal and Disassembly

1. Open the Clamshell, remove 3 Screws from the Clamshell Frame, then lift the front of the
Cover. This helps disengage the Locking Tabs of the LSU from the rear of the Cover. See
Figure 2–1 and Detail 2–1 .
2. Remove 4 Screws from the corners of the LSU Base Plate, then remove 1 Screw from the
outside of each Clamshell Frame. This loosens the LSU Base Plate so that the Catches can
be removed from the Clamshell Frames. See Figure 2–3 .
3. Remove 2 screws, then remove the Right Clamshell Catch.
4. Remove 2 crews, then remove the Left Clamshell Catch.
5. Remove 1 E-ring, then remove the Shaft from either Catch Assembly.

2.6.2 Reassembly and Replacement

Reverse Steps 1 through 5 listed above.
NOTE:

2.6.3 Adjustment

No adjustment of the Latch Assembly is necessary.

2.6.4 Troubleshooting

See Chapter 13 for troubleshooting information.
Chapter 2 – Clamshell
When reinstalling the Top Cover onto the Clamshell, make sure the Latch
Assembly is properly oriented with the Release Lever. See Detail 2–2 .
