6. Remove the printer from the phone book and disconnect 2 Cables from the front of the LVPS.
See Figure 8–4 .
Chapter 8 – Power Supplies
Figure 8–3. Bottom Cover Removal
Bottom
Cover
Locking
Tabs
8–11
