Printronix L1024 Maintenance Manual page 57

Detail 5–3
Corona Neck Is Placed
Under Retaining Tab
DETAIL 5–2
Static Brush
Is Placed In
Front Of
Retaining
Tab
Detail 5–2 and 5–3. Removing the Static Brush and Rear Paper Guide;
6. Transfer Corona Assembly:
a. Remove 2 Screws and lift the Corona Assembly up slightly while sliding it to the left to
disengage the Locking Tabs. See Figure 5–4 .
Chapter 5 – Transfer Subsystem
Corona Contact and Locking Tab
5–11
