5.5 Transfer Charger

1. Open the Clamshell and remove the OPC and Developer Units, and any paper that may be

present in the Printer.

2. Remove the Front Plastic Paper Guide from the Transfer Charger by pressing down on the

center and ends, then sliding it to the left. This disengages the Locking Tabs, allowing the

Paper Guide to be easily removed. See Figure 5–3 .

Chapter 5 – Transfer Subsystem
