Chapter 1 - Introduction; Scope; Conventions; Related Documents - Printronix L1024 Maintenance Manual

Scope

This manual covers service and parts for the L1024 24-ppm continuous-form laser printer. Each section
covers one major subassembly of the printer, in the following order:
Overview
Mechanical Explanation
Electronics Explanation (if appropriate)
Subassembly Removal from the Printer and Disassembly
Subassembly Reassembly and Replacement in the Printer
Adjustment (if needed)
Limited Troubleshooting (See also Chapter 13 for more troubleshooting)

Conventions

The use of LEFT and RIGHT always assumes you are viewing the front of the printer. For instance, the
control panel is on the RIGHT side of the front of the printer.
Notes and Notices that you need to pay special attention to are presented in the following way:
WARNING:
CAUTION:
NOTE:

Related Documents

This manual does not explain how to operate or configure the printer. For that information, refer to the
Operator's Guide and Setup Guide that accompany the printer.

Unit Overview

The L1024 is a 24-ppm continuous-form laser printer. It contains an internal engine controller and an
internal data controller plus a floppy disk drive.
The printer includes the major subassemblies shown in Figure 1–1.
Chapter 1 – Introduction
Chapter 1
Introduction
Possible danger to you or the user.
Possible equipment or data damage may occur.
Extra information for you to consider.
1–1
