6.1.4 Tractor Assembly and Tractor Base

Callout Name
1 Tractor Assembly
2 Frame Assembly, Tractor
3 Frame, Tractor
4 Shaft, Centering Gear
5 Gear, Centering
6 Sensor, TOF
7 Shaft, Guide, Tractor
8 Tractor Assembly w/Arm, Left
9 Tractor Assembly, Left
10 Centering Arm, Left
11 Screw, PPH, TF, 3x16mm (2)
12 Tractor Assembly w/Arm, Right
34 Screw, PPH, TF, 3x12mm (2)
13 Tractor Assembly, Right
14 Centering Arm, Right
15 Stepper Motor Assembly, Tractor
16 Stepper Motor, Tractor
17 Bracket, Mounting, Tractor Motor
18 Screw, PPH, CLFW, 3x6mm, Zinc (2)
33 Cable, Stepper Motor, Tractor
19 Shaft, Tractor Drive
20 Bushing, Tension Roller, Long (4)
21 Board, Tractor Encoder
22 Wheel, Tractor Encoder
23 Gear, Tractor Drive
24 Shaft, Idler, Tractor
25 Paper Support (2)
26 Paper Guide, Tractor
27 Screw, PPH, W/IW, 4x6mm, Zinc (2)
28 Screw, PPH, W/IW, 3x6mm, Zinc (4)
29 E-Ring, 4mm I.D., Chrome (5)
30 E-Ring, 5mm I.D., Chrome
31 Pin, Spring, 2x10mm, SS
32 Screw, PPH, CLFW, 3x6mm, Zinc (3)
6–8
Vendor Part No. Printronix Part No.
202150–501 704539–054
202151–551
200450–001
202153–551
200566–002
202380–501
202381–551
200452–001
030129–316
202382–501
030129–312
202383–551
200451–001
202742–501
202155–551
202156–001
030130–306
202392–551
202157–002
201289–002
202158–551
202159–002
202160–001
202161–001
200456–002
202125–001
030131–406
030131–306
071251–006
071251–008
080660–210
030130–306
Chapter 6 – Paper Feed Subsystem
