4. Remove 1 Screw from the tie wrap that secures the Lamp Power Wire Harness.
5. To change the input voltage of the LVPS, remove 1 Screw and remove the Connector
Bracket. Disconnect the Cable from Connector CN5 or CN6 and connect it to the free one.
CN5 is for 115 VAC and CN6 is for 230 VAC. Place the Connector Bracket over the free
Connector and reinstall 1 Screw. See Figure 8–13 .
8–22
Figure 8–12. LVPS Locking Tabs
Chapter 8 – Power Supplies
