12.8 Base Frame

12.8.1 Removal and Disassembly

1. Open the Clamshell, remove the OPC Drum Unit, the Developer Unit, the Waste Toner
Container, and any paper present in the printer.
2. Remove the Lamp Connector cover by removing 1 Screw. Disconnect the Fuser Lamp and
Thermistor Connectors from the Stepper Motor Board Frame. See Figure 12–10 .
3. Remove the Right Inside Cover by removing 1 Screw, then pressing down on the Warning
Label at the front of the Cover. This releases the Locking Tab from the Right Side Cover. See
Figure 12–10 .
NOTE:
4. Separate the Fuser Lamp Connector and the Thermistor Connector of the LVPS from the
Stepper Motor Board Frame by releasing the Connector Locking Tabs and pushing the
Connectors through the hole in the Printer Base Plate. See Figure 12–10 .
5. Remove the 4 Screws from the printer Back Panel that secure the Data Controller Board.
Slide the Board out part way, then disconnect the Floppy Disk Drive data and power
connectors from the board. Slide the Data Controller Board out the rest of the way and
remove it from the printer.
Chapter 12 – Covers, Frame, and Backplane Board
Upon installation, the groove on the bottom of the Right Inside Cover
should straddle the top edge of the right side of the Tractor Frame.
12–27
