2. Remove either Hinge Cover by pressing the lower Locking Tab with a small screwdriver and
removing the Hinge Cover by lifting it upward. See Detail 2–2 .
NOTE:
Repeat Step 2 for the other hinge cover.
3. Remove 2 screws, then remove the Toner Dust Baffle. See Figure 2–1 .
4. Remove 2 screws, then remove the Latch Assembly from the Top Cover. See Figure 2–1 .
5. Remove the Toner Seals from the Top Cover only if absolutely necessary. See Figure 2–1 .

2.3.2 Reassembly and Replacement

Reverse Steps 1 through 5 listed above.
NOTE:

2.3.3 Adjustment

No adjustment of the Top Cover Assembly is necessary.

2.3.4 Troubleshooting

See Chapter 13 for troubleshooting information.
Chapter 2 – Clamshell
The Clamshell Frame may need to be closed for removal of the Hinge
Covers.
When reinstalling the Top Cover onto the Clamshell, make sure the Latch
Assembly is properly oriented with the Release Lever. See Detail 2–2 on
page 2–15 .
2–13
