6.3.2 Reassembly and Replacement

Reverse Steps 1 through 11 above.
NOTE:
Viewed from the Rear of the Printer

6.3.3 Adjustment

See Detail 6–3.

6.3.4 Troubleshooting

See Chapter 13 for troubleshooting information.
6–16
When the Tension Roller Assembly is reinstalled in the printer, it must be
positioned correctly using the locating pins. Install the left end of the Paper
Guide first, then lock the tabs at the front into the slots on the Roller
Frame. Ensure that the Tabs do not ride too low, under the Tension Roller
Frame. See Detail 6–4.
Detail 6–4. Reinstalling the Paper Guide
Chapter 6 – Paper Feed Subsystem
