Step 15
Backplane
Support
Bracket
NOTE:
17. Remove the Fuser Heat Shield. See Figure 12–18 .
12–36
Figure 12–17. Removing the Base Frame Hardware
The components listed below must be removed, in addition to those listed
above, before the Base Frame can be removed. In order to remove the
Base Frame, most of the components on the top of the Base Plate must be
removed. Therefore, it is advisable that the Base Frame be removed only
in cases where it has been severely damaged and no other options are
available.
,
Step 14
FDD
Frame
Chapter 12 – Covers, Frame, and Backplane Board
,
Step 16
Rear EMI
Bracket
