Printronix L1024 Maintenance Manual page 230

12.4 Base Frame Parts List
Callout Name
1 Base Frame Assembly
2 Frame, Main Base
3 Rubber Foot (4)
4 Bracket, Board Support
5 Bracket, Base Frame, Inner
6 Bracket, Backplane Support
7 Bracket, Rear EMI
8 Guide Rail, PCB (2)
9 Frame (Bracket), Floppy Disk Drive
10 Guide (Bezel), Floppy Disk Drive
11 Backplane Board
12 Clamp, Mounted, Wire Harness
13 Screw, PPH, 3x6mm, Zinc (14)
19 Label, CSA
20 Engine Controller Board
21 Grounding Contact (EMI Tab),
Backplane Board (3)
13 Screw, PPH, 3x6mm, Zinc (12)
14 Wire Harness, HVPS and Tractor
15 Base Plate
16 Bracket, Display Mounting
17 Wire Harness, Fuser Signal
18 Clamp, Wire Harness, Fuser Signal
19 Cable, LCD Control Panel
12–10
Vendor Part No. Printronix Part No.
202279–001
200492–001
202280–001
202281–001
202282–001
202283–001
202284–001
202286–001
202287–002
202289–551
202290–001
030130–306
202214–001
202505–551
202506–001
030130–306
202291–551
202285–001
200603–001
202296–551
202297–001
201153–001
Chapter 12 – Covers, Frame, and Backplane Board
702698–001
704539–104
704539–106
704539–103
704539–118
704539–107
704539–108
704539–105
704539–038
