2.4.2 Reassembly and Replacement

Reverse Steps 1 through 4 listed above, and also refer to Detail 2–2 below.

No adjustment of the Latch Assembly is necessary.

See Chapter 13 for troubleshooting information.

Chapter 2 – Clamshell

When reinstalling the Latch Assembly onto the Top Cover, make sure the

Latch Assembly is properly oriented with the Release Lever. See

Detail 2–2. Correct Latch Release Position

CORRECT LATCH RELEASE
