Peel Off - Intermec EasyCoder 501 XP Installation & Operation Manual

Chapter 5 Paper Load

Peel Off

1
Open the front and right-hand doors.
36
The EasyCoder 501 XP can print on labels, tickets, tags, and paper
strip in various forms. This chapter describes the case when precut
labels fi tted on backing paper (liner) is to be separated from the
backing paper after printing. This requires an optional internal
rewind unit, on which the backing paper is rewound after the labels
have been printed and dispensed.
Peel-off can be used for:
• Self-adhesive labels fi tted on backing paper.
2
Turn the printhead lift knob to "Open" position.
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
