Intermec EasyCoder 501 XP Installation & Operation Manual page 109

Appendix 2 Media Specifi cations
Paper, cont'd.
Tickets with Black Mark
a
e
f
g
c d
TICKETS
PAPER FEED
DIRECTION
108
⇐ a ⇒ Web Width:
Maximum:
Minimum:
⇐ b ⇒ Copy Length:
Minimum:
Maximum: depends on DRAM memory size
⇐ c ⇒ Black Mark Offset:
The distance between the inner edge of the paper web and the inner
b
edge of the black mark must be:
Maximum:
Minimum:
⇐ d ⇒ Black Mark Width:
The detectable width of the black mark must be:
Minimum:
⇐ e ⇒ Black Mark End:
No restriction, but the LSS cannot detect the mark more than 50
mm (1.97") from the inner edge of the paper.
⇐ f ⇒ Black Mark Height:
Maximum:
Common:
Minimum:
⇐ g ⇒ Black Mark Y-Position:
It is recommended to place the black mark as close to the front
edge of the ticket as possible and use a negative Stop Adjust
value to control the paper feed, so the tickets can be properly
torn or cut off.
Media Type Setup:
• Ticket (w mark)
Important! Preprint that may interfere with the detection of the
black mark should be avoided on the back of the paper. However,
the LBLCOND statement allows the sensor to be temporarily
disabled during a specifi ed amount of paper feed in order to avoid
unintentional detection, see Intermec Fingerprint manuals.
The black mark should be non-refl ective carbon black on a whitish
background.
Do not allow any perforations to break the edge of the web, as this
may cause the web to split, resulting in a paper jam.
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
120.0 mm (4.72")
25.4 mm (1.00")
20.0 mm (0.8")
40.0 mm (1.57")
0.0 mm (0.0")
10.0 mm (0.4")
21.3 mm (0.83")
12.5 mm (0.5")
5.0 mm (0.2")
