Chapter 5 Paper Load
Internal Rewind, cont'd.
6b 7
Thread the paper underneath the slack absorber
In case of paper roll with a 76 mm (3") core, fi rst
and forward towards the print unit. The slack
fi t the adapter on the paper supply spool.
absorber can be rotated for better access.
8 9
Thread the paper through the print unit and push
Pull out approximately 40 cm (15") of labels.
it inwards as far as it will go.
