Line Analyzer

Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
The Line Analyzer (LINE_AXP.PRG) is a program written in
the Intermec Fingerprint programming language and intended
to help solving possible communication problems. As the name
implies, the Line Analyzer captures all incoming characters on
a specified communication channel and prints them on one or
several labels.
Printable characters are printed in black-on-white, whereas control
characters and space characters (ASCII 00–32 dec) are printed in
white on a black background.
While the printer is receiving data, the "Ready" control lamp blinks.
There is a 0.5 sec timeout. If no more character has been received
after 0.5 seconds, the program considers the transmission terminated
and prints out a label.
As long as a continuous string of characters is being received,
the program wraps the lines until the label is full and then starts
to print another label. At the bottom of each label, the following
information is printed:
• Page number
• Number of characters printed on the label
• Total of characters received so far
The Line Analyzer is displayed as the option "LINE_ALY.PRG"
under the "SEL. APPLICATION" menu. After the Line Analyzer
has been selected and the printer has started up again, the printer
feeds out two labels and the following menu is displayed:
Line Analyzer
Sel.port(1-4) 1
Enter the desired communication port by means of the numeric
keys on the printer's keyboard:
1 = "uart1:"
2 = "uart2:"
3 = "uart3:"
4 = "centronics:"
5 = "net1:"
If the printer is not fi tted with the specifi ed port, an error message
appears in the display and you can select another port:
Line Analyzer
Error:56
Chapter 9 Intermec Shell Startup Program
83
