Chapter 5 Paper Load

External Supply

1
Use the upper slot in the rear plate when the
supply is at the same level as the printer.
46
The EasyCoder 501 XP can print on labels, tickets, tags, and paper
strip in various forms. This chapter describes the case when an
external paper supply is used, e.g. a stack of fan-fold tickets or
an external paper roll.
Even if it is possible to simply let the paper enter the printer through
either of the two slots in the rear plate, it is recommended to fi t the
optional Intermec Fan-Fold Kit, which provides better guidance of
the paper web using adjustable paper guides fi tted to either the upper
or lower slot in the rear plate.
When using an external paper supply, take care to protect the paper
from dust, dirt and other foreign particles, that can impair the printout
quality or cause unneccessary wear to the printhead.
External supply can be used for:
• Tear off operation
• Cut off operation
• Peel off operation (upper slot only)
2
Use the lower slot in the rear plate when the
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
supply is placed lower than the printer.
