External Supply, cont'd.
3
As an option, the printer can be fi tted with a set of
fan-fold guides in either slot.
5
Fit the fan fold guide in the upper slot, when the
supply is at the same level as the printer.
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
4
The outer guide is adjustable for different paper
widths.
6
Fit the fan fold guide in the lower slot, when the
paper supply is placed lower than the printer.
Chapter 5 Paper Load
47
