Chapter 3
Installation
Print Unit
Printhead Lift Arm
Thermal Printhead
Tear Off/Dispensing Edge
Upper Label Stop Sensor
Guide (removable)
Lower Label Stop Sensor
Guide (removable)
20
The print unit features a high-performance 12 dots/mm (≈300
dpi) thermal printhead with quick-mount fittings to facilitate
replacement.
Label Stop Sensor
Position Adjustment
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
Lift Arm Locking Knob
Printhead Pressure
Adjustment
Paper Guide
Printhead Lift Knob
