Front View
Control Lamps
Connector for optional paper
cutter
(Not used in this printer model)
Print Unit
Front Door
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
The front door is held by a snap-lock. Open the front door to view
the various parts on the printer's front.
Display
Keyboard
Refer to chapter 10 "Options" for information on possible optional
devices fi tted on the printer's front.
Chapter 3
Installation
17
