Chapter 10 Options

Fan Fold Guides

Paper Roll
Retainer

Paper Guide

3" Adapter

Label-Taken
Sensor
86
The fan fold guides are useful for providing a more exact guiding
of the paper, when the paper supply is placed outside the paper
compartment, e.g. in the form of a stack of fan-folded tickets. The
guides come as a fi eld-installable kit with complete installation
instructions.
There are a number of ways to fi t the guides, depending on whether
the upper or lower slot in the rear plate is going to be used.
Instructions for loading the paper is included in the section "External
Supply" in chapter 5 "Paper Load".
The paper roll retainer is intended for applications where the paper
may become misaligned on the paper supply roll. The plastic
wing-shaped retainer is simply pressed onto the paper supply spool
outside the paper roll. No tools are required.
For demanding applications, the paper guide at the rear part of the
print unit can be supplemented with a second paper guide fi tted on the
label slack absorber. This guide is included in the delivery.
The 3 inch/76 mm adapter is included in each delivery of the
EasyCoder 501 XP and makes it possible to use paper rolls with 3
inch/76 mm inner diameter paper cores.
The adapter is pressed onto the paper supply spool and held in
place by a screw. When fi tting the adapter, make sure that the
screw hits a rounded plastic surface, not the metal leaf springs.
Illustrations of how to load the paper using the adapter are to be
found in chapter 5 "Paper Load".
The Label-Taken Sensor (LTS) is a photoelectric sensor fi tted inside
the front door, which enables the printer's fi rmware to detect if
the latest printed label, ticket, tag etc. has been removed before
printing another copy.
The label-taken sensor is usually factory-fi tted, but is also available
as a kit for installation by an authorized service technician. It cannot
be fi tted in combination with a paper cutter.
The LTS can be enabled or disabled by means of the instructions
LTS& ON and LTS& OFF respectively in Intermec Fingerprint and
the Intermec Direct Protocol.
