Media
Compartment
Slack Absorber
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
The media compartment becomes accessible when the right-hand
door is opened. Being held by a magnetic lock, this door can be
opened 180°, or be removed completely by pushing it rearwards.
Ribbon Rewind Spool
Ribbon Supply Spool
Refer to chapter 10 "Options" for information on possible optional
devices fi tted inside the printer's media compartment.
Chapter 3
Installation
Paper Supply
19
