Appendix 1

Technical Data

Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width
Paper Roll Diameter (max)
Paper Roll Core Diameter
Ribbon Width (max)
Print Directions
Modes of Operation
Tear Off
Peel Off
Internal Rewind
Cut Off
Firmware
Operating System
Smooth Fonts
Built-in scalable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Physical Measures
Dimensions (W x L x H)
Weight (excluding media and options)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMM
Real-Time Clock
Power Supply
Mains Voltage
PFC Regulation
Maximum Power Consumption
100
Direct Thermal & Thermal Transfer
12 dots/mm (304.8 dpi)
100 – 300 mm/sec. (≈ 4 – 12"/sec.)
106.6 mm (4.20)"
32767 dots = 409.5 cm
25.4 – 120 mm (1 – 4.72")
205 mm (8")
38 – 40 mm (1.5") or 76 mm (3") w. adapter
110 mm (4.33")
4
Yes
Optional
Optional
Optional
Intermec Fingerprint 7.31
TrueDoc and TrueType fonts
15
36
Intermec Shell 4.4
275 x 480 x 238 mm (10.8 x 18.9 x 9.4")
≈ 13 kgs (28.7 lbs)
+5°C – +40° C (+41°F – +104° F)
20 –80% non-condensing
32 bit RISC
1 – 3 (2 Mbytes each)
1 – 2 (4 Mbytes each)
Option
>90 – <264 V AC, 45 – 65 Hz
IEC 61000-3-2
Continuous 175 W; Peek ≈350W
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
= 1280 dots
1
Internal supply
With internal rewinder
With internal rewinder
With cutter
Incl. Direct Protocol
Unicode fonts
Std. 1 x 2 Mbytes
Std. 1 x 4 Mbytes
10+ years life
