Chapter 12 Maintenance
Printhead Replacement, cont'd.
3
4
Pull the printhead bracket away from the magnet
Remove the paper and transfer ribbon, if any.
in the lift arm
5
6
Snap-lock
Disconnect the hooked printhead bracket fi ngers
Disconnect the two cables from the printhead.
from shaft and pull out the printhead as far as the
Note the snap-lock on the white connector. Pull at
cables allow.
the connectors – not the cables!
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
95
