Internal Rewind

1
Open the front and right-hand doors.
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
The EasyCoder 501 XP can print on labels, tickets, tags, and paper
strip in various forms. This chapter describes the case when printed
labels fi tted on backing paper (liner) or pre-perforated tickets and tags
is rewound on a spool inside the printer. The roll of printed labels,
tickets or tags can then be removed from the spool and be handled
manually. This requires an optional internal rewind unit.
The rewind spool can accommodate
If larger capacity is required, use an external rewinder.
Rewind can be used for:
• Self-adhesive labels on backing paper
• Tickets with gaps with perforations
• Tickets with marks with perforations
2
Turn the printhead lift knob to "Open" position.
Chapter 5 Paper Load
1 1
/ to / of a full-size paper roll.
4 3
