Chapter 5 Paper Load
Peel Off, cont'd.
6
Thread the paper underneath the slack absorber
and forward towards the print unit. The slack
absorber can be rotated for better access.
8
Pull out approx. 40 cm (15") of label web and
remove the labels from the backing paper.
38
7
Thread the paper through the print unit and push
it inwards as far as it will go.
9
Thread the backing paper around the dispenser
edge and back under the print unit.
