Peel-Off (Self-Strip) - Intermec EasyCoder F4 Installation & Operation Manual

Peel-Off
(Self-strip)
1
Open the side door.
Intermec EasyCoder F4 – Installation & Operation Ed. 3
The EasyCoder F4 can print on labels, tickets, tags, and continuous
stock in various forms. This chapter describes the case when
self-adhesive labels are separated from the liner immediately after
printing. The liner is then wound up on an integral liner takeup hub.
This is also known as "Self-strip" operation.
Peel-off operation cannot be performed when Quick-Load guides
are fi tted.
Use the <Feed> key (see fi gure #13) when loading the same type of
media. When switching to a new type of media, or if the printer does
not feed out the media properly, simultaneously press the < Shift>
and <Feed> keys to perform a "testfeed".
Peel-off can only be used for:
• Self-adhesive labels with liner
An optional label taken sensor can hold the printing of the next
label in the batch until the present label has been removed, see
Chapter 10, "Options."
2
Turn the printhead lift lever clockwise to raise
Chapter 5 Media Load
the printhead.
35
