Cut Off, cont'd.
6
Thread the paper underneath the slack absorber
and forward towards the print unit. The slack
absorber can be rotated for better access.
8
This diagram shows the path of the paper web.
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
7
Thread the paper through the print unit and push
it inwards as far as it will go.
9
Turn the printhead lift knob to "Closed" position.
Chapter 5 Paper Load
33
