Setup Parameters, cont'd.
Media, cont'd.
Note:
When printing at ambient tem-
peratures at +15°C (+59°F) or
lower, decrease the max. print
speed value by 100 mm/s, e.g.
from 225 to 125 mm/s.
Thermal Transfer Printing (Europe)
Ribbon Receiving
Type Material
GP02 Vellum
Matte Coated
Transfer Premium
HP07 Premium Tag
Matte Coated
Transfer Premium
Polyethylene Matt
HP66 Premium Tag
Matte Coated
High Gloss White
Polyethylene Gloss
Transfer Premium
Polyethylene Matt
HR03 Polyester Gloss
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
Recommended Settings
Intermec recommends the paper type and print speed settings listed
below to produce the highest possible print quality under normal
conditions and to ensure maximum lifetime of the printhead. Use
the EasySet bar code wand for easy media setup. Ribbon and label
materials are available from Intermec either in standardized types
and sizes, or in special materials and sizes on request.
When adjusting the image darkness for individual requirements or
new label materials, proceed as follows:
Direct Thermal Printing
Keep the Label Factor at the recommended value for the type
of direct thermal paper. Then decrease or increase the Label
Constant for lighter or darker images respectively, depending on the
requirements of the images or of the new label material.
Thermal Transfer Printing
Keep the Ribbon Factor for each quality at the recommended value.
Then decrease or increase the Ribbon Constant for lighter or darker
images respectively. For a new label material, start with an average
Ribbon Constant value for the ribbon quality in question.
Ribbon Ribbon
Constant Factor
80 25
80 25
70 25
105 25
100 25
90 25
85 25
105 25
100 25
95 25
95 25
90 25
85 25
100 30
Chapter 7 Setting Up the Printer
Label Max Rec. Print Speed (mm/sec)
Offset Picket Fence Bar Code
0 200
0 200
0 250
0 100
0 225
0 300
0 200
0 250
0 250
0 300
0 200
0 300
0 225
0 250
Ladder Bar Code
200
200
250
100
200
225
200
200
200
225
200
250
200
200
