Chapter 6 Thermal Transfer Printing
Ribbon Load, cont'd.
5c
#3
In case of 110 mm (4.3") ribbon width, compress
the bobbin and move it so it snaps into the 3:rd
7
Without releasing the ribbon, turn the printhead
lift knob to "Closed" position to lock the
50
110 mm
(4.3")
groove.
6
2.
Press the ribbon roll onto the ribbon supply spool
(1) and thread the ribbon through the print unit.
Pull out approx. 20 cm (8) of ribbon
8
Press the cardboard core at the front end of the
ribbon onto the take-up spool. Both spools should
rotate counter-clockwise.
Intermec EasyCoder 501 XP – Installation & Operation Ed. 4
1.
