Appendix 1
Technical Data
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Width (min/max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width (max)
Ribbon Roll Diameter (outer)
Ribbon Roll Core Diameter (inner)
Print Directions
Modes of Operation
Tear-Off (Straight-through)
Peel-Off (Self-strip)
Firmware
Operating System
Built-in fonts (std)
Built-in bar code symbologies (std)
Physical Measures
Dimensions (W x L x H)
Weight (excluding media)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board DRAM SIMM
Power Supply
Mains Voltage
PFC Regulation
Maximum Power Consumption
62
Direct Thermal (Thermal Transfer as option)
8 dots/mm (203.2 dpi)
100 to 200 mm/sec. ( 4 to 8 inches/sec.)
56 mm (2.2 inches)
32767 dots = 409.5 cm(161.25 inches)
25 to 60 mm (1 to 2.36 inches)
40 to 60 mm (1.57 to 2.36 inches)
213 mm (8.38 inches)
38 to 40 mm (1.5 inches) or 76 mm (3 inches)
25 to 60 mm (1 to 2.36 inches)
62 mm (2.44 inches)
25.4 mm (1.00 inches)
4
Yes
Optional
Intermec IPL 3
3 scaleable + 21 simulated bitmap fonts
25
194 x 397 x 178 mm (7.64 x 15.63 x 7.00 inches) With long side door
5.5 kg (12 pounds)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
32 bit RISC
2 sockets for 2 or 4MB each
1
>90 to <264 VAC, 45 to 65Hz
IEC 61000-3-2
Continuous 140W; Peek 300W
Intermec EasyCoder F2 – Installation & Operation IPL Version, Ed. 1
= 448 dots
1
Standard edge guide
Quick-Load guides
Short door/no takeup
200 m (655 ft) ribbon
With liner takeup unit
Depending on model
Std. 1 x 2MB
Std. 4MB
